John Deere 690E LC Long Front Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
38.92ft in
C
Shipping Height Of Unit
10.67ft in
I
Max Cutting Height
44.67ft in
J
Max Loading Height
38.67ft in
K
Max Reach Along Ground
50ft in
M
Max Digging Depth
37.33ft in
Boom/Stick Option (Hex) 1
Arm 21ft 1in (6440mm)
Dimensions
E
Ground Clearance
1.5ft in
G
Height To Top Of Cab
9.33ft in
B
Width To Outside Of Tracks
9.92ft in
D
Length Of Track On Ground
12ft in
H
Tail Swing Radius
8.67ft in
Removal Counterweight Clearance
3.58ft in
Undercarriage
F
Track Gauge
7.83ft in
N
Shoe Size
26in
Max Travel Speed
3.85mph
Drawbar Pull
40300lb
Number Of Carrier Rollers Per Side
2
Number Of Shoes Per Side
49
Number Of Track Rollers Per Side
9
Ground Pressure
5.6psi
Specifications
Engine
Engine Make
2240
Engine Model
e 6068T
Gross Power
140hp
Net Power
130hp
Max Torque
424lb ft
Displacement
414cu in
Operational
Operating Weight
43890lb
Fuel Capacity
85gal
Cooling System Fluid Capacity
44gal
Hydraulic System Fluid Capacity
84gal
Engine Oil Capacity
20gal
Operating Voltage
24V
Swing Drive Fluid Capacity
4gal
Alternator Supplied Amperage
42amps
Hydraulic System Relief Valve Pressure
5000psi
Hydraulic Pump Flow Capacity
100gal/min
Swing Mechanism
Swing Speed
13rpm
