John Deere 672D Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

28.89ft in

B

Width Over Tires

8.17ft in

D

Wheelbase

20.08ft in

F

Front Ground Clearance

1.93ft in

G

Tandem Axle Wheelbase

5.06ft in

H

Blade Base

8.43ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6068H

Net Power Gear 1-2

165hp

Power Measured @

2000rpm

Net Power Gear 5-6

185hp

Torque Measured @

1000rpm

Max Power

185hp

Net Power Gears 7-8

185hp

Net Torque Gears 1-2

554lb ft

Net Torque Gears 3-4

611lb ft

Net Torque Gears 5-6

625lb ft

Net Torque Gears 7-8

625lb ft

Displacement

414cu in

Aspiration

turbocharged with air-to-air aftercooler

Net Power Gear 4-6

165hp

Operational

Std Operation Weight - Front Axle

9610lb

Std Operation Weight - Rear Axle

24020lb

Std Operation Weight - Total

33630lb

Max Operation Weight - Total

46799.8lb

Fuel Capacity

106gal

Cooling System Fluid Capacity

12gal

Hydraulic System Fluid Capacity

14gal

Transmission Fluid Capacity

6gal

Rear Diff/Final Drive Fluid Capacity

9.5gal

Circle Gearbox Fluid Capacity

1.5gal

Tandem Case Fluid Capacity (each)

20gal

Tire Size

14.00R24 Radial PR

Operating Voltage

24V

Alternator Supplied Amperage

100amps

Transmission

Transmission Type

Powershift with direct drive

Number of Gears - Forward

8

Number of Gears - Reverse

8

Max Speed - Forward

24.9mph

Max Speed - Reverse

24.9mph

Steering

Articulation Angle

22degrees

Turning Radius

23.5ft in

Front Axle

Wheel Lean

20degrees

Oscillation - Total

32degrees

Ground Clearance

2ft in

Hydraulic System

Pump Type

Variable-displacement Piston

Pump Flow

54.7gal/min

Relief Valve Pressure

2750psi

Moldboard

Moldboard Width

12.1ft in

Moldboard Height

24.1in

Moldboard Thickness

0.9in

Side Shift Left

26.8in

Side Shift Right

26.8in

Blade Pull at Max Weight

42120lb

Circle

Diameter

59.9in

Rotation

360degrees

Shift Left

31in

Shift Right

28.6in

Max Reach Outside Tires - Left

82.7in

Max Reach Outside Tires - Right

81.9in

Max Lift Above Ground

18.6in

Blade Tip Angle - Front

42degrees

Blade Tip Angle - Rear

5degrees

Dimensions

Height to Top of Isomount Cab

10.5ft in

Overall Length

28.9ft in

Width Over Tires

8.2ft in

Wheelbase

20.1ft in

Blade Base

8.5ft in

Tandem Axle Wheelbase

5.1ft in

Front Ground Clearance

2ft in
