John Deere 672CH Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

28.15ft in

B

Width Over Tires

8.08ft in

D

Wheelbase

19.59ft in

G

Tandem Axle Wheelbase

5.06ft in

F

Front Ground Clearance

1.84ft in

H

Blade Base

8.76ft in

Height To Top Of Isomount Cab

10.18ft in


Specifications

Engine

Number Of Cylinders

6

Net Power Gear 4-6

178hp

Engine Make

2240

Engine Model

6068H

Net Power Gear 1-2

145hp

Power Measured @

2000rpm

Net Power Gear 5-6

198hp

Torque Measured @

1000rpm

Max Power

198hp

Net Power Gears 7-8

198hp

Net Torque Gears 1-2

554lb ft

Net Torque Gears 3-4

611lb ft

Net Torque Gears 5-6

625lb ft

Net Torque Gears 7-8

625lb ft

Displacement

414cu in

Aspiration

Turbocharged with Aftercooler

Operational

Std Operation Weight - Front Axle

10060lb

Std Operation Weight - Rear Axle

22260lb

Hydraulic System Fluid Capacity

15.5gal

Std Operation Weight - Total

32320lb

Max Operation Weight - Front Axle

11180lb

Max Operation Weight - Rear Axle

25870lb

Oil System Fluid Capacity

6.4gal

Max Operation Weight - Total

37050lb

Fuel Capacity

106gal

Cooling System Fluid Capacity

11gal

Transmission Fluid Capacity

10gal

Rear Diff/Final Drive Fluid Capacity

9.5gal

Circle Gearbox Fluid Capacity

4gal

Tandem Case Fluid Capacity (Each)

20gal

Tire Size

13.00-24

Operating Voltage

24V

Alternator Supplied Amperage

55amps

Steering

Articulation Angle

25degrees

Turning Radius

22.6ft in

Transmission

Transmission Type

Power Shift

Number Of Gears - Forward

8

Number Of Gears - Reverse

8

Max Speed - Forward

25mph

Max Speed - Reverse

25mph

Front Axle

Wheel Lean

20degrees

Oscillation - Total

32degrees

Ground Clearance

1.9ft in

Moldboard

Moldboard Width

12ft in

Moldboard Height

24in

Moldboard Thickness

0.9in

Side Shift Left

26.9in

Side Shift Right

26.9in

Blade Pull At Max Weight

39310lb

Hydraulic System

Pump Type

Closed center variable displacement

Pump Flow

45.6gal/min

Relief Valve Pressure

2550psi

Circle

Diameter

59.9in

Rotation

360degrees

Shift Left

31in

Shift Right

28.6in

Max Reach Outside Tires - Left

85.1in

Max Reach Outside Tires - Right

83.1in

Max Lift Above Ground

17.5in

Blade Tip Angle - Front

49degrees

Blade Tip Angle - Rear

5degrees
