John Deere 646 Compactor
Units
Dimensions
Dimensions
A
Length With Blade On Ground
20.67ft in
B
Width Over Wheels
8.7ft in
C
Height To Top Of Cab
10.27ft in
D
Wheelbase
11.95ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Net Power
131hp
Gross Power
141.1hp
Power Measured @
2200rpm
Displacement
404cu in
Max Torque
348lb ft
Torque Measured @
1600rpm
Aspiration
Turbocharged
Operational
Operating Weight
30012lb
Fuel Capacity
50gal
Hydraulic System Fluid Capacity
17.5gal
Engine Oil Capacity
4.3gal
Cooling System Fluid Capacity
9gal
Transmission Fluid Capacity
9.8gal
Operating Voltage
12V
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
2
Wheels
Front Wheels Drum Width
23in
Front Wheels Drum Diameter
55in
Rear Wheels Drum Width
23in
Rear Wheels Drum Diameter
55in
Blade
Blade Capacity
4.5yd3
Width
9.3ft in
