John Deere 644H Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
27.12ft in
B
Width Over Tires
9.43ft in
C
Height To Top Of Cab
11.17ft in
D
Wheelbase
10.5ft in
E
Ground Clearance
1.52ft in
F
Hinge Pin Max Height
13.6ft in
G
Dump Clearance At Max Lift
8.91ft in
K
Max Lift Height
12.9ft in
I
Fork Tine Length
5.01ft in
Reach At Max Height And Dump
3.71ft in
Length With Out Forks On Ground
28.35ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6081H
Gross Power
180hp
Net Power
221hp
Power Measured @
2200rpm
Max Torque
755lb ft
Torque Measured @
1300rpm
Torque Rise
75%
Displacement
496cu in
Aspiration
Turbocharged
Operational
Operating Weight
38876lb
Fuel Capacity
100gal
Turning Radius
18.1ft in
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Rear Axle Oscillation
26degrees
Static Tipping Load - Bucket
31210.1lb
Static Tipping Load - Forks
22782lb
Tire Size
23.5-25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed Forward
22mph
Max Speed Reverse
15.5mph
Hydraulic System
Pump Type
Piston Pump
Relief Valve Setting
3600psi
Pump Flow Capacity
68gal/min
Raise Time
6.2sec
Dump Time
1.4sec
Lower Time
3sec
Bucket
Breakout Force
28976lb
Bucket Capacity - Heaped
4.3yd3
Bucket Capacity - Struck
3.8yd3
