John Deere 6120R Utility Tractor

John Deere 6120R Utility Tractor Specs front
John Deere 6120R Utility Tractor Specs front
John Deere 6120R Utility Tractor Specs side
John Deere 6120R Utility Tractor Specs side
John Deere 6120R Utility Tractor Specs back
John Deere 6120R Utility Tractor Specs back
Units

Specifications

Engine

Number of Cylinders

4

Engine Manufacturer

John Deere PowerTech PSS

Rated engine speed

88 kW 120 hp

Cylinder liners

Wet sleeve

Fuel tank capacity

51.6 gal

Rated PTO power

70 @ 2100 kW 94 @ 2100 hp

Displacement

4.5 L 275 cu in.

Aspiration

Dual Series Turbocharger with fixed geometry first stage-variable geometry second stage, air-to-air aftercooling and cooled exhaust gas recirculation

Underhood muffler

Yes

Power Take-Off(PTO)

Standard

540/1000 RPM, 1-3/8 In. Independent Rear Reversible PTO

Optional

3-Speed 540/540E/1000 Rear Reversible PTO with Power Assisted PTO Shifting

PTO Actuation

Electrohydraulic

Transmission

Standard transmission; forward/reverse

24/24 AutoQuad PLUS ECO; 40 km/h 24/24 AutoQuad PLUS ECO; 25 mph

Optional transmission; forward/reverse

PowrQuad PLUS 16F/16R (30); AutoQuad PLUS ECO 24F/24R Transmission (40); AutoQuad PLUS ECO 24F/24R (50); Infinitely Variable Transmission (40); Infinitely Variable Transmission (50) km/h PowrQuad PLUS 16F/16R (19); AutoQuad PLUS ECO 24F/24R Transmission (25); AutoQuad PLUS ECO 24F/24R (31); Infinitely Variable Transmission (25); Infinitely Variable Transmission (31) mph

Clutch, wet/dry

Wet

Creeper

Included with IVT; Optional on PowrQuad and AutoQuad transmissions

Reverser

Left-hand base

On-the-Go Shifting (Yes/No/Partial)

Yes

Tires

2WD

Front 10.0-16.0 Rear 18.4R34

MFWD

Front 12.4R24 Rear 16.9R30

Hydraulic

Maximum operating pressure

2900.8 psi

Remote control valves available

2-450 Series mechanical SCVs standard, up to 4-450 Series electronic SCVs optional

Hitch Draft Control Load Sense Type

Electrohydraulic

Sensing type

Electronic lower link

Joystick SCV control

Mechanical or electronic

Pump rated output

Standard 114 Advertised L/min 30.1 Advertised gpm

Hydraulic Type

Closed-center, pressure/flow compensated

Hitch Category (SAE Designation)

2/3N

Final Drive

Final Drive Type

Inboard planetary three pinion

Differential controls

Electrohydraulic

Availability

Front Yes

Engage On-the-Go Rear Differential Lock

Yes

Axle Type

Flange Axle

Brakes, Type and Control

Wet-disk hydraulic power brakes

Dimensions

Approximate shipping weight (open-station; cab)

2WD - 5100 kg 11244 lb, MFWD - 5470 kg 12059 lb

Rear Tread Range

@WD - 1604-2302 mm 63.1-90.6 in.

Front Tread Range

2WD - 1485-2438 mm 58.5-96 in., MFWD - 1616 to 1924 mm 63.6 to 75.7 in.

Wheelbase - 2WD

101.6 in

Wheelbase - MFWD

101.6 in

Front Axle Clearance - 2WD

18.5 in

Front Axle Clearance - MFWD

18.5 in
