John Deere 548G Series III Skidder

John Deere 548G Series III Skidder Specs front
John Deere 548G Series III Skidder Specs front
John Deere 548G Series III Skidder Specs back
John Deere 548G Series III Skidder Specs back
John Deere 548G Series III Skidder Specs extended
John Deere 548G Series III Skidder Specs extended
Units

Dimensions

Dimensions

A

Overall Length

20.77 in

B

Overall Width

9.51 ft in

C

Height to Top of Cab

9.88 ft in

D

Wheelbase

9.59 ft in

E

Ground Clearance

1.68 ft in

F

Max Height of Boom

9.82 ft in

G

Height of Grapple from Ground

2.84 ft in

H

Reach of Grapple at Ground Level

6.47 ft in

I

Tong Opening at Tips

7.09 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6068H

Gross Power

129 hp

Power Measured @

2200 rpm

Displacement

414 cu in

Aspiration

turbocharged

Operational

Operating Weight

23690 lb

Fuel Capacity

50 gal

Hydraulic System Fluid Capacity

12.2 gal

Operational Voltage

12 V

Alternator Supplied Amperage

120 amps

Axle Oscillation

30 degrees

Steering Angle

45 degrees

Tire Size

28L-26

Transmission

Transmission Type

direct-drive power shift

Number of Forward Gears

8

Number of Reverse Gears

7

Max Speed - Forward

12.4 mph

Max Speed - Reverse

9.4 mph

Hydraulic

Pump Type

variable-displacement axial piston

Pump Flow

29.1 gal/min

Relief Valve Pressure

3100 psi

Dimensions

Overall Width

9.6 ft in

Blade Width

7.2 ft in

Height to Top of Cab

9.9 ft in

Max Blade Height

47.6 in

Wheelbase

9.6 ft in

Ground Clearance

1.7 ft in

Overall Length

20.8 in

Height of Grapple From Ground

2.9 ft in

Reach of Grapple at Ground Level

6.5 ft in

Max Height of Boom

9.9 ft in

Tong Opening at Tips

7.1 ft in

Grapple Capacity - tongs tip to tip

8 ft2

Drum Diameter

8 in

Max Line Pull - bare drum

35025.3 lb

Max Line Speed

122.1 ft/min
