John Deere 5090R Utility Tractor

John Deere 5090R Utility Tractor Specs front
John Deere 5090R Utility Tractor Specs front
John Deere 5090R Utility Tractor Specs side
John Deere 5090R Utility Tractor Specs side
John Deere 5090R Utility Tractor Specs back
John Deere 5090R Utility Tractor Specs back
Units

Specifications

Engine

Number of Cylinders

4

Family

FJDXL04.5211

Cylinder liners

Wet sleeved

Rated power

At 2200 per ISO 97/68/EC: 66 kW 90 engine hp

Rated PTO power

At 2100 per SAE: 57.8 kW 77.5 PTO hp

PTO torque rise

At 1600 rpm: 36 rpm

Aspiration

Turbocharged/Air-to-Air Aftercooled

Description

John Deere 4045 PowerTech PWL

Displacement

274.7 cu in

Capacities

Fuel Tank - diesel

38.1 gal

Transmission

Clutch, wet/dry

Wet

Creeper

16F/16R CommandQuad Manual with creeper

Reverser

Standard: Left hand, electronic Optional: Joystick reverser

Transmission Type

Standard: 16F/16R CommandQuad Manual Optional: 16F/16R CommandQuad Manual with creeper 32F/16R Command8

Tires

Turning radius with brakes

11.1 ft

Turning radius without brakes

12.1 ft in

Front

MFWD: 12.4R24 (320/85R24) R1W Radial

Rear

18.4R30 R1W Radial

Wheel tread range

MFWD: 1148-2000 mm 45.2-78.7 in.

Hydraulic

Joystick SCV control

Optional

Pump rated output

Standard: 96.6 L/min 25.5 gpm Optional: 117.3 L/min 31 gpm

Hydraulic Type

Standard: Open Center Optional: Pressure-and-Flow Compensated (PFC) System

Available flow at a single rear SCV

Standard: 73 L/min 19.3 gpm Optional: 100 L/min 26.4 gpm

Dimensions

Approximate shipping weight (open-station; cab)

MFWD: 4450 kg 9811 lb

Wheelbase - MFWD

88.6 in

Rear Hitch

Hitch draft control load sense type

Electrohydraulic

Remote control valves available

2 upt to 4 total

Hitch category (SAE designation)

Category 2/1

Maximum lift capacity behind lift points

Standard: 3038 kg 6697 lb Optional: 3564 kg 7857 lb

Sensing type

Lower link

Rear Power Take -Off (PTO)

Engine rpm (at rated PTO speeds)

540 at 2100 rpm 540E at 1645 rpm 1000 at 2103 rpm

PTO actuation

Electrohydraulic

Rear Power Take -Off (PTO) Type

Standard: 540/540E/1000

Rear Axle

Final Drive Type

Inboard Planetary

Differential controls

Electrohydraulic

Axle Type

Flanged

Brakes,type and control

Hydraulic wet disc
