John Deere 50 ZTS Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
17.43ft in
I
Max Cutting Height
16.93ft in
J
Max Loading Height
11.5ft in
K
Max Reach Along Ground
19.08ft in
L
Max Vertical Wall Digging Depth
8.75ft in
M
Max Digging Depth
11.83ft in
Boom/Stick Option (Hex) 1
Arm Length 4ft. 5.0in. (1340mm )
Dimensions
B
Width To Outside Of Tracks
6.58ft in
D
Length Of Track On Ground
8.08ft in
E
Ground Clearance
1.08ft in
G
Height To Top Of Cab
8.58ft in
H
Tail Swing Radius
3.25ft in
Removal Counterweight Clearance
2ft in
Undercarriage
Max Travel Speed
2.8mph
Ground Pressure
3.82psi
Specifications
Engine
Engine Make
2353
Engine Model
4LE1
Gross Power
38hp
Displacement
133cu in
Operational
Operating Weight
10565lb
Fuel Capacity
13.2gal
Operating Voltage
12V
Hydraulic System Fluid Capacity
11.8gal
Alternator Supplied Amperage
35amps
Hydraulic Pump Flow Capacity
21.9gal/min
Swing Mechanism
Swing Speed
7.4rpm
