John Deere 400G Crawler Tractor

John Deere 400G Crawler Tractor Specs front
John Deere 400G Crawler Tractor Specs front
John Deere 400G Crawler Tractor Specs side
John Deere 400G Crawler Tractor Specs side
John Deere 400G Crawler Tractor Specs back
John Deere 400G Crawler Tractor Specs back
Units

Dimensions

Dimensions

D

Length of Track on Ground

6.5 ft in

E

Ground Clearance

0.97 ft in

F

Length w/o Blade

11.92 ft in

Undercarriage

H

Standard Shoe Size

14 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2240

Engine Model

4039D

Gross Power

63 hp

Net Power

60 hp

Power Measured @

2100 rpm

Max Torque

188 lb ft

Displacement

239 cu in

Torque Measured @

1300 rpm

Operational

Operating Weight

11820 lb

Fuel Capacity

31 gal

Cooling System Fluid Capacity

3.3 gal

Hydraulic Fluid Capacity

8.5 gal

Final Drives Fluid Capacity

14 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Transmission

Transmission Type

Hi-Lo-Reverse with direct drive

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

6.2 mph

Max Speed - Reverse

5.9 mph

Undercarriage

Ground Pressure

6.1 psi

Ground Contact Area

1940 in2

Standard Shoe Size

14 in

Number of Shoes per Side

36

Number of Track Rollers per Side

5

Track Pitch

50 in

Hydraulic System

Pump type

Gear

Relief Valve Pressure

2750 psi

Pump Flow Capacity

11 gal/min

Standard Blade

Width

7.5 ft in

Height

28.6 in

Capacity

1.1 yd3

Blade Angle (both directions)

50 degrees

Cutting Depth

20.6 in

Dimensions

Length w/o Blade

12 ft in

Length of Track on Ground

6.5 ft in

Ground Clearance

1 ft in
