John Deere 337E Log Loader

John Deere 337E Log Loader Specs front
John Deere 337E Log Loader Specs front
John Deere 337E Log Loader Specs side
John Deere 337E Log Loader Specs side
John Deere 337E Log Loader Specs extended
John Deere 337E Log Loader Specs extended
Units

Specifications

Driveline

Engine Model

6068 HTJ57 PowerTech PVS

Displacement

415 cu in

Engine Manufacturer

John Deere

Engine Torque

532.6 lb ft

Emission Rating

Tier 4

Rated Speed

2000 rpm

Engine Output - Net

159.6 hp

Engine Output - Gross

173 hp

Torque Rise

17 %

Capacities

Fuel Tank - diesel

89.9 gal

Hydraulic Tank

39.9 gal

Alternator Output

120 amps

Performance

System Voltage

12 V

Slew Speed

10 rpm

5ft lift @ 10ft radius

8972.9 lb

5ft lift @ 15ft radius

16380.4 lb

5ft lift @ 20ft radius

12125.5 lb

5ft lift @ 25ft radius

9612.2 lb

5ft lift @ 30ft radius

3445.9 lb

10ft lift @ 10ft radius

19797.6 lb

10ft lift @ 15ft radius

14572.6 lb

10ft lift @ 20ft radius

11375.9 lb

10ft lift @ 25ft radius

9457.9 lb

10ft lift @ 30ft radius

4177.8 lb

Pump

Axial Piston

Weights

Operating Weight

30580.4 lb

Dimensions

Super Structure Width

8.6 ft in

Boom Horizontal Reach

30.2 ft in

Slewing Angle

360 degrees

Height Over Cab

161.9 ft in

Carrier/Base Length

12.5 ft in
