John Deere 328D Skid Steer Loader
Units
Dimensions
Dimensions
E
Ground Clearance
11.62in
F
Length W/O Bucket
9.81ft in
H
Reach At Max Lift And Dump
31.34in
Length
141.74in
Angle Of Departure
31degrees
Turning Radius - Tts870
7.12ft in
Height To Top Of Rops
84.65in
Hinge Pin Height, Maximum Height
126.78in
Specifications
Engine
Emissions Certification
EPA Tier 3/EU Stage IIIA
Number Of Cylinders
5
Engine Make
John Deere PowerTech
Engine Model
E 5030HT
Gross Power
85hp
Air Cleaner
Dry dual element
Net Torque
221.3lb ft
Net Power
80hp
Power Measured @
2800rpm
Torque Measured @
2000rpm
Net Torque Rise
43%
Aspiration
Turbocharged and intercooled
Displacement
183.1cu in
Operational
Operational Weight
8408.5lb
Hydraulic System Fluid Capacity
21.2gal
Max Speed
12mph
Tire Size
14 x 17.5 12 PR Extra Wall
Operating Voltage
12V
Alternator Supplied Amperage
70amps
Loader
Rollback - Ground Level
35degrees
Dump Height
8.5ft in
Tipping Load (Iso 14397)
5600lb
Bucket Breakout Force (Iso 14397)
7750lb
Operating Load Rating
2950lb
Boom Breakout Force
5000lb
Dump Angle @ Max. Height
45degrees
Width Without Bucket
6.4ft in
Hydraulic
Pump Flow Capacity
32.3gal/min
Axles
Maximum Axle Torque
6235lb ft
Tractive Effort
8610lb ft
Hydraulic
Hydraulic Horsepower-Standard Flow
46hp
Hydraulic Horsepower_High Flow
77hp
System Pressure At Couplers
3450psi
