John Deere 325G Multi Terrain Loader

John Deere 325G Multi Terrain Loader Specs front
John Deere 325G Multi Terrain Loader Specs front
John Deere 325G Multi Terrain Loader Specs back
John Deere 325G Multi Terrain Loader Specs back
John Deere 325G Multi Terrain Loader Specs extended
John Deere 325G Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

C

Height to Top of Cab

6.76 ft in

E

Ground Clearance

9.45 in

I

Track Gauge

4.93 ft in


Specifications

Driveline

Engine Model

4TNV98CT

Displacement

201.4 cu in

Engine Manufacturer

Yanmar

Emission Rating

Tier 4

Rated Speed

2500 rpm

Engine Output - Net

70 hp

Engine Output - Gross

74 hp

Track Shoe Width

12.6 in

Aspiration

Turbo

Torque

206.6 lb ft

Capacities

Fuel Tank - diesel

20.9 gal

Description

Lift Geometry

Vertical

Performance

Ground Bearing Pressure

5.7 psi

Pump Flow

18.5 gal/min

Speed - Maximum

5.8 mph

Breakout - Lift

5238.1 lb

Breakout - Bucket

8745.1 lb

Hydraulic Power

36.8 hp

System Pressure

3450 psi

Speed - Maximum Option

8.2 mph

Tipping Load

7407.6 lb

Rated Operating Capacity

2592.7 lb

Hydraulic Power - Option, kW (hp)

53.1 hp

Pump Flow - Option

26.7 gal/min

Weights

Operating Weight

9508.6 lb

Dimensions

Rollback - Ground Level

34

Track Gauge

5 ft in

Rear Departure Angle

30.5

Width - No Bucket

71.7 in

Height to Hinge Pin

126 in

Dump Angle

41

Dump Height - Maximum

102 in

Length - No Bucket

112.3 in

Length - With Bucket

136.3 in

Height to Top of Cab

6.8 ft in

Ground Clearance

9.5 in
