John Deere 317G Multi Terrain Loader

John Deere 317G Multi Terrain Loader Specs front
John Deere 317G Multi Terrain Loader Specs front
John Deere 317G Multi Terrain Loader Specs back
John Deere 317G Multi Terrain Loader Specs back
John Deere 317G Multi Terrain Loader Specs extended
John Deere 317G Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

C

Height to Top of Cab

6.53 ft in

E

Ground Clearance

8.27 in

I

Track Gauge

4.37 ft in


Specifications

Driveline

Engine Model

4TNV86CHT

Displacement

128.2 cu in

Engine Manufacturer

Yanmar

Emission Rating

Tier 4

Rated Speed

2600 rpm

Engine Output - Net

61.2 hp

Engine Output - Gross

65.1 hp

Track Shoe Width

12.6 in

Aspiration

Turbo

Torque

152.7 lb ft

Capacities

Fuel Tank - diesel

18.8 gal

Description

Lift Geometry

Vertical

Performance

Ground Bearing Pressure

5.6 psi

Pump Flow

15.6 gal/min

Speed - Maximum

7.1 mph

Breakout - Lift

4990.8 lb

Breakout - Bucket

5980 lb

Hydraulic Power

31.1 hp

System Pressure

3450 psi

Tipping Load

6076 lb

Rated Operating Capacity

2127.5 lb

Weights

Operating Weight

8203.5 lb

Dimensions

Rollback - Ground Level

30

Track Gauge

4.4 ft in

Rear Departure Angle

32.3

Width - No Bucket

65 in

Height to Hinge Pin

120.9 in

Dump Angle

42

Dump Height - Maximum

95.7 in

Length - No Bucket

103.6 in

Length - With Bucket

127.6 in

Height to Top of Cab

6.6 ft in

Ground Clearance

8.3 in
