John Deere 310L EP Loader Backhoe
Units
Dimensions
Dimensions
D
Wheelbase
7.19ft in
E
Ground Clearance
0.97ft in
Dump Height
8.9ft in
Dump Reach - General Purpose
28.9in
Height Over Std Stick
11.23ft in
Max Length With Std. Stick
23.76ft in
Shovel Pin Height - General Purpose
11.32ft in
Width - General Purpose Shovel
2184 mm (7 ft 2 in)
Bucket Rotation - Position 1
190
Width Over Tires
7.09ft in
Digging Depth
4.22in
Specifications
Engine
Engine Output-Net
70hp
Battery
12
Engine Make
John Deere
Engine Model
PowerTech E 4045HT072
Rated Speed
1900rpm
Displacement
274.7cu in
Capacities
Fuel Tank
37gal
Hydraulic Tank
11.9gal
Stick Tearout
6991.6lb
Boom Lift - Maximum Reach - Non-Extending Dipper
2330.3lb
4wd Front Axle
1.8gal
Rear Axle
4.8gal
Bucket Tearout - Non-Extending Dipper
10835.8lb
Shovel Breakout - General Purpose
9352.1lb
Lift To Full Height - General Purpose Shovel
6832.2lb
Shovel Capacity - Standard General Purpose
1.1yd3
Transmission
Transmission Type
Powershift
Weights
Operating Weights
14799.7lb
Weight - 4wd, Gp, Std Stick
14799.7lb
Hydraulic
Pump Type
Tandem Gear Pump
Pump Flow Capacity
31.5gal/min
Brakes
Actuation
Hydraulic with Power Assist
Brakes Type
Wet Multi Disc
