John Deere 300GLC Midi Excavator

John Deere 300GLC Midi Excavator Specs front
John Deere 300GLC Midi Excavator Specs front
John Deere 300GLC Midi Excavator Specs side
John Deere 300GLC Midi Excavator Specs side
John Deere 300GLC Midi Excavator Specs extended
John Deere 300GLC Midi Excavator Specs extended
Units

Dimensions

Dimensions

E

Ground Clearance

1.68 ft in

H

Tail Swing Radius

10.67 ft in

F

Track Gauge

6.53 ft in


Specifications

Driveline

Displacement

415 cu in

Engine Manufacturer

John Deere

Emission Rating

Tier 4

Rated Speed

1900 rpm

Engine Output - Net

222.7 hp

Track Shoe Width

31.5 in

Number Of Cylinders

6

Capacities

Fuel Tank - diesel

135.8 gal

Hydraulic Tank

41.3 gal

System Voltage

24 V

Number Of Batteries

2

Performance

Tractive Force

55303 lb

Slew Speed

10.3 rpm

Ground Bearing Pressure

6.4 psi

Slew Torque

66.8 lb ft

Boost Pressure

55.2 psi

Breakout - Bucket

45411.5 lb

Bucket Pressure

343

Dipper Tearout

28550.8 lb

End lift - 7.5m Reach

17438.6 lb

Gradeability

70 %

Main Pumps - Maximum Flow

124.7 gal/min

Side lift - 7.5m Reach

10273.6 lb

Travel Speed - High

3.3 mph

Weights

Operating Weight

68674 lb

Dimensions

Digging Reach - Mono Boom

37 ft in

Dump Height - Mono Boom

24.8 ft in

Dig Height - Mono Boom

34.4 ft in

Track Gauge

6.6 ft in

Dig depth - 2.44m 8 ft flat bottom

25.3 ft in

Standard Dipper

12.4 ft in

Track length on ground

13.3 ft in

Transport Height - Maximum

11.1 ft in

Transport Length Mono Boom

35.2 ft in

Undercarriage Overall Length

16.3 ft in

Overall Width

11.2 ft in

Ground Clearance

1.7 ft in

Tail Swing Radius

10.7 ft in

Dig Depth - Mono Boom

25.9 ft in

Width over standard tracks

11.2 ft in

Ground Level Reach - Mono Boom

36.4 ft in
