John Deere 27D Mini Excavator

John Deere 27D Mini Excavator Specs front
John Deere 27D Mini Excavator Specs front
John Deere 27D Mini Excavator Specs side
John Deere 27D Mini Excavator Specs side
John Deere 27D Mini Excavator Specs extended
John Deere 27D Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

13.78 ft in

C

Shipping Height of Unit

8.08 ft in

I

Max Cutting Height

14.64 ft in

J

Max Loading Height

10.5 ft in

K

Max Reach Along Ground

- -

M

Max Digging Depth

8.58 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

- -

C

Shipping Height of Unit

- -

I

Max Cutting Height

- -

J

Max Loading Height

- -

K

Max Reach Along Ground

- -

M

Max Digging Depth

- -

Dimensions

B

Width to Outside of Tracks

5.08 ft in

D

Length of Track on Ground

4.92 ft in

E

Ground Clearance

1 ft in

G

Height to Top of Cab

8.08 ft in

H

Tail Swing Radius

2.55 ft in

Undercarriage

N

Shoe Size

12 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2348

Engine Model

3TNV88

Net Power

26.4 hp

Power Measured @

2200 rpm

Displacement

100 cu in

Aspiration

Natural

Operational

Operating Weight

6393.5 lb

Fuel Capacity

10.5 gal

Hydraulic System Fluid Capacity

9.2 gal

Hydraulic Pump Flow Capacity

16.4 gal/min

Swing Mechanism

Swing Speed

9.1 rpm

Undercarriage

Shoe Size

12 in

Ground Pressure

3.9 psi

Max Travel Speed

2.8 mph

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Arm 3ft. 10in. 1170mm

Shipping Height of Unit

8.1 ft in

Shipping Length of Unit

13.8 ft in

Max Digging Depth

8.6 ft in

Max Cutting Height

14.7 ft in

Max Loading Height

10.5 ft in

Dimensions

Width to Outside of Tracks

5.1 ft in

Height to Top of Cab

8.1 ft in

Ground Clearance

1 ft in

Removal Counterweight Clearance

1.9 ft in

Tail Swing Radius

2.6 ft in

Length of Track on Ground

5 ft in
