John Deere 27 ZTS Mini Excavator

John Deere 27 ZTS Mini Excavator Specs front
John Deere 27 ZTS Mini Excavator Specs front
John Deere 27 ZTS Mini Excavator Specs side
John Deere 27 ZTS Mini Excavator Specs side
John Deere 27 ZTS Mini Excavator Specs extended
John Deere 27 ZTS Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

3.83 ft in

I

Max Cutting Height

13.92 ft in

J

Max Loading Height

9.08 ft in

K

Max Reach Along Ground

13.92 ft in

L

Max Vertical Wall Digging Depth

8.67 ft in

M

Max Digging Depth

8.67 ft in

Dimensions

B

Width to Outside of Tracks

5.09 ft in

D

Length of Track on Ground

6.33 ft in

E

Ground Clearance

1.07 ft in

G

Height to Top of Cab

8.37 ft in

H

Tail Swing Radius

2.58 ft in


Specifications

Engine

Engine Make

2353

Engine Model

3LD1

Gross Power

22 hp

Power Measured @

2450 rpm

Displacement

91.5 cu in

Operational

Operating Weight

6360 lb

Fuel Capacity

10.5 gal

Hydraulic System Fluid Capacity

7.9 gal

Operating Voltage

12 V

Alternator Supplied Amperage

35 amps

Hydraulic Pump Flow Capacity

12 gal/min

Swing Mechanism

Swing Speed

8.1 rpm

Undercarriage

Ground Pressure

4.3 psi

Max Travel Speed

3 mph

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Arm Length

Shipping Length of Unit

3.9 ft in

Max Digging Depth

8.7 ft in

Max Reach Along Ground

14 ft in

Max Cutting Height

14 ft in

Max Loading Height

9.1 ft in

Max Vertical Wall Digging Depth

8.7 ft in

Dimensions

Width to Outside of Tracks

5.1 ft in

Height to Top of Cab

8.4 ft in

Ground Clearance

1.1 ft in

Removal Counterweight Clearance

1.8 ft in

Tail Swing Radius

2.6 ft in

Length of Track on Ground

6.4 ft in
