John Deere 1910G Forwarder

Forwarder
Forwarder
Forwarder
Forwarder
Forwarder
Forwarder
Units

Dimensions

Dimensions

D

Wheelbase

20.51 ft in

E

Ground Clearance

2.63 ft in

G

Width of Bunk Area

9.69 ft in


Specifications

Driveline

Engine Model

PowerTech Plus 6090

Displacement

549.3 cu in

Engine Manufacturer

John Deere

Engine Output

268.3 hp

Engine Torque

969.9 lb ft

Drive Configuration

8 x 8

Transmission

Hydrostatic-Mechanical

Std tire size front

26.5 - 20

Std tire size rear

26.5 - 20

Capacities

Fuel Tank - diesel

48.7 gal

Hydraulic Tank

48.9 gal

Alternator Output

150 amps

Performance

Lifting Moment - Standard Crane

151 kNm

Load Capacity

19 tonnes

Travel Speed

13.1 mph

Tractive Force

51706.1 lb

System Voltage

24 V

Pump Capacity

2.3 in

Dimensions

Horizontal Reach

27.9 ft in

Load Length

221.9 in

Width

3090 mm

Transport Height

12.8 ft in

Carrier/Base Length

37.7 ft in

Wheelbase

20.6 ft in

Ground Clearance

2.7 ft in

Width of Bunk Area

9.7 ft in
