John Deere 190E Midi Excavator

Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

20.8ft in

I

Max Cutting Height

13.5ft in

J

Max Loading Height

16.8ft in

K

Max Reach Along Ground

20.3ft in

L

Max Vertical Wall Digging Depth

11.6ft in

M

Max Digging Depth

13.7ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

22.4ft in

I

Max Cutting Height

24.9ft in

J

Max Loading Height

17.9ft in

K

Max Reach Along Ground

21.1ft in

L

Max Vertical Wall Digging Depth

13.4ft in

M

Max Digging Depth

15.3ft in

Dimensions

B

Width to Outside of Tracks

7.1ft in

D

Length of Track on Ground

6.1ft in

E

Ground Clearance

1.4ft in

G

Height to Top of Cab

8.5ft in

H

Tail Swing Radius

5.7ft in


Specifications

Engine

Engine Model

190E / 4039D

Gross Power

60hp

Net Power

55hp

Displacement

239cu in

Max Torque

153lb ft

Operational

Operating Weight

16300lb

Fuel Capacity

35.7gal

Cooling System Fluid Capacity

11.8gal

Hydraulic System Fluid Capacity

17.5gal

Engine Oil Capacity

9gal

Swing Drive Fluid Capacity

1.5gal

Operating Voltage

24V

Alternator Supplied Amperage

42amps

Hydraulic System Relief Valve Pressure

3770psi

Hydraulic Pump Flow Capacity

6.2gal/min

Swing Mechanism

Swing Speed

15rpm

Undercarriage

Number of Shoes per Side

37

Number of Carrier Rollers per Side

5

Number of Track Rollers per Side

1

Ground Pressure

3.5psi

Max Travel Speed

3.1mph

Drawbar Pull

10360lb

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Arm length 5ft. 4in. (1.62m )

Shipping Length of Unit

20.8ft in

Max Digging Depth

13.7ft in

Max Reach Along Ground

20.3ft in

Max Cutting Height

13.5ft in

Max Loading Height

16.8ft in

Max Vertical Wall Digging Depth

11.6ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Arm Length 6ft. 11in. (2.12m )

Shipping Length of Unit

22.4ft in

Max Digging Depth

15.3ft in

Max Reach Along Ground

21.1ft in

Max Cutting Height

24.9ft in

Max Loading Height

17.9ft in

Max Vertical Wall Digging Depth

13.4ft in

Dimensions

Width to Outside of Tracks

7.1ft in

Height to Top of Cab

8.5ft in

Ground Clearance

1.4ft in

Removal Counterweight Clearance

5.7ft in

Tail Swing Radius

5.7ft in

Length of Track on Ground

6.1ft in
