John Deere 1270G Harvester

Units

Dimensions

Dimensions

B

Overall Width

9.01 ft in

D

Wheelbase

13.69 ft in

E

Ground Clearance

25.75 in


Specifications

Driveline

Engine Model

6090HTJ

Engine Manufacturer

John Deere

Engine Output

254.8 hp

Engine Torque

922 lb ft

Drive Configuration

6 x 6

Std tire size front

26.5

Std tire size rear

34

Emission Rating

Tier 3

Rated Speed

1900 rpm

Transmission Type

Hydrostatic-Mechanical

Capacities

Fuel Tank - diesel

118.9 gal

Hydraulic Tank

79.3 gal

Number of Alternators

1

Reference Harvesting Head

H480C

Felling Diameter

28 in

Delimbing Diameter

26.8 in

Delimbing Feed Rate

5.3 m/sec

Delimbing Feed Force

30 kN

Travel Speed

13.7 mph

System Voltage

24 V

Pump Capacity

2.3 in

Description

Crane Model

CH7

Weights

Weight - With Reference Head

48942.7 lb

Weight - Without Reference Head

46208.9 lb

Operating Weight

48942.7 lb

Dimensions

Horizontal Reach

28.3 ft in

Ground Clearance

25.8 in

Transport Height

12.5 ft in

Carrier/Base Length

25.3 ft in

Overall Width

9.1 ft in

Wheelbase

13.7 ft in
