John Deere 1270D Harvester

Units

Dimensions

Boom

H

Max Reach w/ Head

30.5 ft in

Dimensions

B

Overall Width

9.08 ft in

C

Height to Top of Cab

12.17 ft in

D

Wheelbase

13.25 ft in

Undercarriage

E

Ground Clearance

2.05 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6090HTJ

Net Power

214.6 hp

Power Measured @

1400 rpm

Displacement

552 cu in

Max Torque

811.4 lb ft

Torque Measured @

1400 rpm

Aspiration

Turbocharged

Operational

Operating Weight

38580 lb

Fuel Capacity

127 gal

Hydraulic System Fluid Capacity

76.6 gal

Cooling System Fluid Capacity

7.4 gal

Operating Voltage

24 V

Alternator Supplied Amperage

140 amps

Max Speed

15.5 mph

Undercarriage

Ground Clearance

2.1 ft in

Ground Pressure

10.1 psi

DRIVE SYSTEM

Tire Size - front

600 x 26.5, 20 PR Forest King F NK

Tire Size - rear

600 x 34, 14 PR TRS NK

Boom

Max Reach w/ Head

30.5 ft in

Dimensions

Forward Tilt

11 degrees

Side Tilt

15 degrees

Height to Top of Cab

12.2 ft in

Overall Width

9.1 ft in

Wheelbase

13.3 ft in


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Max Reach w/ Head

Net Power

190 hp

Operating Weight

31945 lb

Max Reach w/ Head

32.9 ft in

Net Power

190 hp

Operating Weight

33289.9 lb

Max Reach w/ Head

36.1 ft in
