John Deere 1110G Forwarder

Forwarder
Forwarder
Forwarder
Forwarder
Forwarder
Forwarder
Units

Dimensions

Dimensions

D

Wheelbase

192.92 in

E

Ground Clearance

2.17 ft in


Specifications

Driveline

Engine Model

PowerTech Plus 6068

Displacement

415 cu in

Engine Manufacturer

John Deere

Engine Output

194.5 hp

Engine Torque

638 lb ft

Drive Configuration

8 x 8

Transmission

Hydrostatic-Mechanical

Std tire size front

26.5 - 20

Std tire size rear

26.5 - 20

Capacities

Fuel Tank - diesel

44.2 gal

Hydraulic Tank

42.6 gal

Alternator Output

150 amps

Performance

Lifting Moment - Standard Crane

102 (75)

Load Capacity

12 tonnes

Travel Speed

14.3 mph

Tractive Force

35969.5 lb

System Voltage

24 V

Pump Capacity

55.2 in

Weights

Operating Weight

37765.2 lb

Dimensions

Horizontal Reach

23.7 ft in

Load Length

177.2 in

Transport Height

12.7 ft in

Width - Fixed Bunk

106.3 in

Width

106.3 in

Wheelbase

193 in

Carrier/Base Length

32.3 ft in

Ground Clearance

2.2 ft in
