JLG M450AJ Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
21.2in
B
Overall Width
5.9ft in
C
Overall Height - Mast Lowered
6.7ft in
D
Wheelbase
6.7ft in
E
Ground Clearance
9in
Platform Dimension A
2.6ft in
Platform Dimension B
5ft in
Turning Radius
10.4ft in
Platform
F
Max Platform Height
45ft in
G
Max Horizontal Reach
23.9ft in
Max Working Height
25.3ft in
Specifications
Engine
Engine Model
Kubota
Gross Power
6.7hp
Fuel Type
Diesel
System Voltage
48V
Number Of Batteries
8
Operational
Operating Weight
14700lb
Fuel Capacity
4gal
Tire Size
240/55-17.5
Tire Fill/Type
Pnuematic
Performance
Drive Speed
3.2mph
Swing
260degrees
Gradeability
30%
Platform Capacity
500lb
Jib - Range Of Articulation
141degrees
Hydraulic
Hydraulic Reservoir
4gal
