JLG 600A Narrow Boom Lift

JLG 600A Narrow Boom Lift Specs side
JLG 600A Narrow Boom Lift Specs side
JLG 600A Narrow Boom Lift Specs back
JLG 600A Narrow Boom Lift Specs back
JLG 600A Narrow Boom Lift Specs extended
JLG 600A Narrow Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

26.42 in

B

Overall Width

6.99 ft in

C

Overall Height - mast lowered

8.34 ft in

D

Wheelbase

8.01 ft in

E

Ground Clearance

7.88 in

Platform

F

Max Platform Height

60.44 ft in

G

Max Horizontal Reach

39.6 ft in


Specifications

Engine

Engine Make

2349

Engine Model

D2011L04

Gross Power

49 hp

Fuel Type

Diesel

Operational

Operating Weight

24098.8 lb

Fuel Capacity

30.1 gal

Hydraulic System Fluid Capacity

30.6 gal

Max Speed

4.3 mph

Tire Size

14x17.5

Tire Fill/Type

Air Boss

Platform

Max Platform Height

60.5 ft in

Max Horizontal Reach

39.6 ft in

Max Platform Weight Capacity

992.1 lb

Platform Inner Length

96.1 in

Platform Inner Width

35.9 in

Platform Rotation

180 degrees

Dimensions

Wheelbase

8.1 ft in

Overall Length

26.5 in

Overall Width

7 ft in

Overall Height - mast lowered

8.4 ft in

Turning Radius

11.2 ft in

Ground Clearance

7.9 in


Compare similar models

Manufacturer / Model

Operating Weight

Max Platform Weight Capacity

Operating Weight

22149.9 lb

Max Platform Weight Capacity

992.1 lb

Operating Weight

22149.9 lb

Max Platform Weight Capacity

992.1 lb

Operating Weight

21461 lb

Max Platform Weight Capacity

1000.9 lb
