JLG 534D10-45 Telescopic Forklift

JLG 534D10-45 Telescopic Forklift Specs front
JLG 534D10-45 Telescopic Forklift Specs front
JLG 534D10-45 Telescopic Forklift Specs side
JLG 534D10-45 Telescopic Forklift Specs side
JLG 534D10-45 Telescopic Forklift Specs extended
JLG 534D10-45 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

19.72 ft in

B

Width Over Tires

8.21 ft in

C

Overall Height

7.75 ft in

D

Wheelbase

11.23 ft in

E

Ground Clearance

1.61 ft in

Lift

F

Max Lift Height

44.95 ft in

G

Max Forward Reach

31.5 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2347

Engine Model

QSB4.5

Gross Power

110 hp

Power Measured @

2500 rpm

Displacement

274.7 cu in

Aspiration

turbocharged

Operational

Operating Weight

26799.4 lb

Fuel Capacity

38.1 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Drawbar Pull

21001.3 lb

Tire Size

14.0x24-12PR

Transmission

Transmission Type

hydrostatic

Max Speed - forward

19.1 mph

Hydraulic

Pump Type

single-section gear

Pump Flow Capacity

40.1 gal/min

Lift

Max Lift Capacity

8999.3 lb

Max Lift Height

45 ft in

Max Load at Max Height

6999.7 lb

Max Forward Reach

31.5 ft in

Max Load at Max Reach

1000.9 lb

Dimensions

Length to Fork Face

19.8 ft in

Width Over Tires

8.3 ft in

Overall Height

7.8 ft in

Wheelbase

11.3 ft in

Ground Clearance

1.7 ft in

Turning Radius Outside Tires

14.6 ft in
