JLG 450AJ 2WD Boom Lift

JLG 450AJ 2WD Boom Lift Specs side
JLG 450AJ 2WD Boom Lift Specs side
JLG 450AJ 2WD Boom Lift Specs back
JLG 450AJ 2WD Boom Lift Specs back
JLG 450AJ 2WD Boom Lift Specs extended
JLG 450AJ 2WD Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

21.43 in

B

Overall Width

6.83 ft in

C

Overall Height - mast lowered

7.42 ft in

D

Wheelbase

6.5 ft in

E

Ground Clearance

14.18 in

Platform

F

Max Platform Height

45.02 ft in

G

Max Horizontal Reach

24.51 ft in


Specifications

Engine

Engine Make

2349

Engine Model

F3M1011

Gross Power

47 hp

Fuel Type

Diesel

Operational

Operating Weight

16499.4 lb

Fuel Capacity

16.6 gal

Hydraulic System Fluid Capacity

30.1 gal

Max Speed

3.5 mph

Tire Size

33/1550x16.5

Tire Fill/Type

Superwide

Platform

Max Platform Height

45.1 ft in

Max Horizontal Reach

24.6 ft in

Max Platform Weight Capacity

500.5 lb

Platform Inner Length

72.1 in

Platform Inner Width

30 in

Platform Rotation

145 degrees

Dimensions

Wheelbase

6.5 ft in

Overall Length

21.5 in

Overall Width

6.9 ft in

Overall Height - mast lowered

7.5 ft in

Turning Radius

14.1 ft in

Ground Clearance

14.2 in


Compare similar models

Manufacturer / Model

Operating Weight

Max Platform Weight Capacity

Operating Weight

16499.4 lb

Max Platform Weight Capacity

500.5 lb

Operating Weight

16301 lb

Max Platform Weight Capacity

500.5 lb

Operating Weight

16750.8 lb

Max Platform Weight Capacity

500.5 lb
