JLG 4017 Telescopic Forklift

JLG 4017 Telescopic Forklift Specs front
JLG 4017 Telescopic Forklift Specs front
JLG 4017 Telescopic Forklift Specs side
JLG 4017 Telescopic Forklift Specs side
JLG 4017 Telescopic Forklift Specs extended
JLG 4017 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

15.62 ft in

B

Width Over Tires

7.81 ft in

C

Overall Height

8.27 ft in

D

Wheelbase

9.36 ft in

E

Ground Clearance

16.54 ft in

Lift

F

Max Lift Height

54.79 ft in

G

Max Forward Reach

41.02 ft in


Specifications

Engine

Engine Make

2351

Engine Model

Turbo Diesel

Gross Power

100 hp

Aspiration

turbocharged

Operational

Operating Weight

26671.6 lb

Fuel Capacity

37 gal

Hydraulic System Fluid Capacity

42.3 gal

Tire Size

405/70-24

Transmission

Transmission Type

powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - forward

15.6 mph

Max Speed - reverse

15.6 mph

Hydraulic

Pump Type

load sensing piston

Pump Flow Capacity

34.9 gal/min

Lift

Max Lift Capacity

8818.5 lb

Max Lift Height

54.8 ft in

Max Load at Max Height

6613.9 lb

Max Forward Reach

41.1 ft in

Max Load at Max Reach

1543.3 lb

Dimensions

Length to Fork Face

15.7 ft in

Width Over Tires

7.9 ft in

Overall Height

8.3 ft in

Wheelbase

9.4 ft in

Ground Clearance

16.6 ft in

Turning Radius Outside Tires

12.5 ft in
