JCB VMT390 Vibratory Smooth Drum Roller

JCB VMT390 Vibratory Smooth Drum Roller Specs front
JCB VMT390 Vibratory Smooth Drum Roller Specs front
JCB VMT390 Vibratory Smooth Drum Roller Specs side
JCB VMT390 Vibratory Smooth Drum Roller Specs side
JCB VMT390 Vibratory Smooth Drum Roller Specs back
JCB VMT390 Vibratory Smooth Drum Roller Specs back
Units

Dimensions

Dimensions

A

Overall Length

9.29 in

C

Height to Top of Cab

6.22 ft in

D

Wheelbase

7.55 in

E

Ground Clearance

12.01 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2334

Engine Model

V 2203

Gross Power

46.6 hp

Power Measured @

2800 rpm

Displacement

134 cu in

Operational

Operating Weight

8598 lb

Fuel Capacity

20.1 gal

Engine Oil Capacity

2.6 gal

Hydraulic System Fluid Capacity

15.9 gal

Max Speed

6.8 mph

Operating Voltage

12 V

Alternator Supplied Amperage

45 amps

Drum

Drum Width

51.2 in

Drum Diameter

31.5 in

Static Linear Load

84 lb/in

Vibration Frequency 1

55 Hz

Nominal Amplitude - High

0.1 in

Centrifugal Force - High

10791 lb

Dimensions

Wheelbase

7.6 in

Overall Length

9.3 in

Height to Top of Cab

6.3 ft in

Ground Clearance

12.1 in
