JCB TM300-52 Integrated Tool Carrier

JCB TM300-52 Integrated Tool Carrier Specs front
JCB TM300-52 Integrated Tool Carrier Specs front
JCB TM300-52 Integrated Tool Carrier Specs extended_1
JCB TM300-52 Integrated Tool Carrier Specs extended_1
JCB TM300-52 Integrated Tool Carrier Specs extended_2
JCB TM300-52 Integrated Tool Carrier Specs extended_2
JCB TM300-52 Integrated Tool Carrier Specs extended_3
JCB TM300-52 Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

21.76 ft in

B

Width Over Tires

7.49 ft in

C

Height to Top of Cab

8.83 ft in

D

Wheelbase

8.21 ft in

E

Ground Clearance

1.45 ft in

G

Dump Clearance at Max Lift

13.47 ft in

I

Fork Tine Length

3.94 ft in

K

Max Lift Height

17.07 ft in


Specifications

Engine

Engine Make

2257

Engine Model

1104C-44TA

Gross Power

121.4 hp

Net Power

147.6 hp

Power Measured @

2000 rpm

Max Torque

320.2 lb ft

Torque Measured @

1400 rpm

Displacement

Operational

Operating Weight

17769.3 lb

Fuel Capacity

26.5 gal

Cooling System Fluid Capacity

5.3 gal

Engine Oil Capacity

2.9 gal

Transmission Fluid Capacity

5.1 gal

Front Diff Fluid Capacity

5.3 gal

Rear Diff Fluid Capacity

5.3 gal

Hydraulic System Fluid Capacity

29.1 gal

Operating Voltage

12 V

Alternator Supplied Amperage

100 amps

Transmission

Transmission Type

4 Speed Powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed Forward

21.8 mph

Max Speed Reverse

21.8 mph

Hydraulic System

Pump Type

Twin Gear

Relief Valve Setting

230

Pump Flow Capacity

31.8 gal/min

Bucket

Bucket Capacity - heaped

1.3 yd3

Dimensions

Width Over Tires

7.5 ft in

Height to Top of Cab

8.9 ft in

Wheelbase

8.3 ft in

Ground Clearance

1.5 ft in

Length w/ Bucket on Ground

21.8 ft in

Dump Clearance at Max Lift

13.5 ft in

Reach at Max Height and Dump

3.6 ft in

Fork Tine Length

4 ft in

Max Lift Height

17.1 ft in
