JCB TLT30D 4X4 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
9.32ft in
D
Wheelbase
5.84ft in
Free Lift
53.15in
Height Of Operators Seat - High
48.86in
Height Of Operators Seat - Low
48.08in
Height Of Overhead Guard- Low
86.62in
Height Of Overhead Guard - Standard
90.56in
Boom Horizontal Reach
7.85ft in
Max Height Of Boom
15.77ft in
Max Lift Height
13.13ft in
Maximum Width Of Machine
55.12in
Minimum Ground Clearance
6.5in
Reach @ Ground Level
7.32ft in
Rollback @ Ground
37degrees
Turning Radius
9.83ft in
Load Centre
19.69in
Fork Carriage Width
47.25in
Specifications
Engine
Number Of Cylinders
4
Tier Compliant
Tier 3 Stage III
Engine Output - Gross
49.7hp
Engine Make
D-Perkins/G-G.M.
Engine Model
404 2.2
Power Measured @
2600rpm
Displacement
134.3cu in
Capacities
Diesel Tank Capacity
11.7gal
Shovel Dump Height
100.4in
Struck Capacity
0.7yd3
Lift Capacities
6613.9lb
Shovel Capacity - Standard General Purpose
0.8yd3
Operational
Gradeability-Laden
30%
Shovel Width
54.6in
Gradeability-Unladen
28%
Travel Speed
12.5mph
Transmission Type
TCR
Hydraulic System
Working Pressure
170 bar
Oil Flow For Attachments
7.4gal/min
Brakes
Park Brake
Hand
