JCB JS 300 NLC Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (Hex) 1

A

Shipping Length Of Unit

36.33ft in

C

Shipping Height Of Unit

11.83ft in

I

Max Cutting Height

31.92ft in

J

Max Loading Height

22ft in

K

Max Reach Along Ground

32.41ft in

L

Max Vertical Wall Digging Depth

16.5ft in

M

Max Digging Depth

20.92ft in

Minimum Swing Radius

183.98in

Max Digging Reach

33.09ft in

Boom/Stick Option (Hex) 1

Dipper Length 2.21m Boom 6.45m

Max.Dumping Height

22.3ft in

Boom/Stick Option (Hex) 2

A

Shipping Length Of Unit

36ft in

I

Max Cutting Height

32.75ft in

C

Shipping Height Of Unit

11.75ft in

J

Max Loading Height

22.67ft in

K

Max Reach Along Ground

34ft in

L

Max Vertical Wall Digging Depth

18.43ft in

M

Max Digging Depth

22.33ft in

Max Digging Reach

34.43ft in

Minimum Swing Radius

182.6in

Max.Dumping Height

22.98ft in

Boom/Stick Option (Hex) 2

Dipper Lenght 2.63m Boom 6.45m

Boom/Stick Option (Hex) 3

A

Shipping Length Of Unit

35.67ft in

I

Max Cutting Height

33.67ft in

J

Max Loading Height

23.58ft in

C

Shipping Height Of Unit

11.25ft in

K

Max Reach Along Ground

35.92ft in

L

Max Vertical Wall Digging Depth

20.83ft in

M

Max Digging Depth

24.25ft in

Max Digging Reach

36.21ft in

Boom/Stick Option (Hex) 3

Dipper Length 3.23m Boom 6.45m

Max.Dumping Height

23.89ft in

Minimum Swing Radius

159.73in

Boom/Stick Option (Hex) 4

A

Shipping Length Of Unit

36ft in

C

Shipping Height Of Unit

12.67ft in

I

Max Cutting Height

34.58ft in

J

Max Loading Height

24.5ft in

K

Max Reach Along Ground

38.33ft in

M

Max Digging Depth

26.92ft in

Max Vertical Wall Dig Depth

23.33ft in

Max Digging Reach

38.64ft in

Boom/Stick Option (Hex) 4

Dipper Length 4.03m Boom 6.45m

Max.Dumping Height

24.8ft in

Minimum Swing Radius

178in

Dimensions

E

Ground Clearance

1.81ft in

G

Height To Top Of Cab

9.81ft in

B

Width To Outside Of Tracks

9.5ft in

D

Length Of Track On Ground

13008.54ft in

H

Tail Swing Radius

10.67ft in

O

Counterweight Clearance

3.93ft in

Track Length On Ground

13.1ft in

Undercarriage Overall Length

15.89ft in

Removal Counterweight Clearance

3.92ft in

Undercarriage

F

Track Gauge

7.5ft in

N

Shoe Size

24in

Max Travel Speed

3mph

Number Of Track Rollers Per Side

2

Ground Pressure

9.1psi

Number Of Shoes Per Side

50

Drawbar Pull

54904lb

Number Of Carrier Rollers Per Side

9

Track Adjustment

Grease cylinder type.


Specifications

Slew System

Slew Motor

Axial piston type

Slew Brake

Hydraulic braking plus automatic spring applied disc type parking brake.

Slew Torque

JS330:111kNm , JS370: 129kNm

Slew Gear

arge diameter, internally toothed fully sealed grease bath lubricated

Electrical System

System

24V

Alternator

100Amp

Batteries

2 X 12 Volt

Engine

Diesel Fuel Tank Capacity - Standard Tank

12.5gal

Number Of Cylinders

6

Tier 1 Engine: Model

Tier 4 Final compliant

Engine Make

2353

Engine Model

MTU 6R1000

Net Power

281hp

Gross Power

271hp

Power Measured @

2000rpm

Aspiration

Turbocharged and intercooled

Displacement

469.9cu in

Operational

Operating Weight

71052.8lb

Fuel Capacity

155.9gal

Cooling System Fluid Capacity

10.1gal

Hydraulic System Fluid Capacity

113.6gal

Engine Oil Capacity

6.7gal

Operating Voltage

24V

Swing Drive Fluid Capacity

3.9gal

Alternator Supplied Amperage

50amps

Hydraulic System Relief Valve Pressure

4627psi

Hydraulic Pump Flow Capacity

153.3gal/min

Swing Mechanism

Swing Speed

9.5rpm

Buckets

Reference Bucket Capacity

2yd3

Minimum Bucket Capacity

1.6yd3

Maximum Bucket Capacity

2.5yd3

Brakes

Parking Brake

Disc type

Brakes Type

Fully hydrostatic, two speed with autoshift.

Service Brake

Hydraulic counter balance valve.

Travel Speed

3.3mph

Gradeability

70
