JCB 540-170 Telescopic Forklift

JCB 540-170 Telescopic Forklift Specs front
JCB 540-170 Telescopic Forklift Specs front
JCB 540-170 Telescopic Forklift Specs side
JCB 540-170 Telescopic Forklift Specs side
JCB 540-170 Telescopic Forklift Specs extended
JCB 540-170 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

20.87 ft in

B

Width Over Tires

8.01 ft in

C

Overall Height

8.83 ft in

D

Wheelbase

9.03 ft in

E

Ground Clearance

1.32 ft in

Lift

F

Max Lift Height

54.79 ft in

G

Max Forward Reach

41.02 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2257

Engine Model

JCB EcoMAX T4i/IIIB

Gross Power

100 hp

Power Measured @

2200 rpm

Max Torque

313.5 lb ft

Torque Measured @

1200 rpm

Displacement

268.6 cu in

Aspiration

turbocharged cooled

Operational

Operating Weight

8818.5 lb

Fuel Capacity

33.1 gal

Hydraulic System Fluid Capacity

39.7 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Tire Size

15.5/80-24

Transmission

Transmission Type

4-speed powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

15.6 mph

Max Speed - reverse

15.6 mph

Hydraulic System

Extend

18.3 sec

Bucket crowd

4.6 sec

Retract

16.7 sec

Max operating pressure

260 bar

Main hydraulic pumps

90+72 L

Hydraulic

Pump Flow Capacity

42.8 gal/min

Relief Valve Pressure

3770 psi

Hydraulic System

Raise Time

22.7 sec

Dump Time

4.2 sec

Lower Time

23.4 sec

Lift

Max Lift Capacity

8818.5 lb

Max Lift Height

54.8 ft in

Max Load at Max Height

5511.6 lb

Max Forward Reach

41.1 ft in

Max Load at Max Reach

1322.8 lb

Dimensions

Lift capacity to full height

3307 lb

Dump angle

8.8 degrees

Weight

26587.8 lb

Length to Fork Face

20.9 ft in

Width Over Tires

8.1 ft in

Overall Height

8.9 ft in

Wheelbase

9.1 ft in

Ground Clearance

1.4 ft in

Turning Radius Outside Tires

13.5 ft in
