JCB 535-95 Sway Telescopic Forklift

JCB 535-95 Sway Telescopic Forklift Specs front
JCB 535-95 Sway Telescopic Forklift Specs front
JCB 535-95 Sway Telescopic Forklift Specs side
JCB 535-95 Sway Telescopic Forklift Specs side
JCB 535-95 Sway Telescopic Forklift Specs extended
JCB 535-95 Sway Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

16.38 ft in

B

Width Over Tires

7.52 ft in

C

Overall Height

8.17 ft in

D

Wheelbase

9.03 ft in

E

Ground Clearance

1.32 ft in

Lift

F

Max Lift Height

31.17 ft in

G

Max Forward Reach

21.4 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2257

Engine Model

444

Gross Power

100 hp

Power Measured @

2200 rpm

Max Torque

306.1 lb ft

Torque Measured @

1200 rpm

Displacement

268.6 cu in

Aspiration

turbo

Operational

Operating Weight

7716.2 lb

Fuel Capacity

33.1 gal

Hydraulic System Fluid Capacity

29.9 gal

Operating Voltage

12 V

Alternator Supplied Amperage

95 amps

Tire Size

15.5R24

Transmission

Transmission Type

4-speed powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

19.9 mph

Max Speed - reverse

19.9 mph

Hydraulic

Pump Flow Capacity

21.7 gal/min

Relief Valve Pressure

3500 psi

Lift

Max Lift Capacity

7716.2 lb

Max Lift Height

31.2 ft in

Max Load at Max Height

3527.4 lb

Max Forward Reach

21.4 ft in

Max Load at Max Reach

1212.6 lb

Dimensions

Length to Fork Face

16.4 ft in

Width Over Tires

7.6 ft in

Overall Height

8.2 ft in

Wheelbase

9.1 ft in

Ground Clearance

1.4 ft in

Turning Radius Outside Tires

12.2 ft in
