JCB 520-50 Telescopic Forklift

JCB 520-50 Telescopic Forklift Specs front
JCB 520-50 Telescopic Forklift Specs front
JCB 520-50 Telescopic Forklift Specs side
JCB 520-50 Telescopic Forklift Specs side
JCB 520-50 Telescopic Forklift Specs extended
JCB 520-50 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

11.78 ft in

B

Width Over Tires

6.04 ft in

C

Overall Height

6.96 ft in

D

Wheelbase

6.57 ft in

E

Ground Clearance

0.99 ft in

Lift

F

Max Lift Height

16.41 ft in

G

Max Forward Reach

9.26 ft in


Specifications

Engine

Number of Cylinders

4

Gross Power

77 hp

Max Torque

213.9 lb ft

Displacement

134.3 cu in

Aspiration

Naturally aspirated

Operational

Operating Weight

9700 lb

Fuel Capacity

16 gal

Hydraulic System Fluid Capacity

8.7 gal

Operating Voltage

12 V

Alternator Supplied Amperage

55 amps

Tire Size

10.00 x18 10PR

Transmission

Transmission Type

syncro shuttle transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

18.7 mph

Max Speed - reverse

18.7 mph

Hydraulic

Pump Flow Capacity

17.2 gal/min

Relief Valve Pressure

3500 psi

Lift

Max Lift Capacity

4409.3 lb

Max Lift Height

16.5 ft in

Max Load at Max Height

4409.3 lb

Max Forward Reach

9.3 ft in

Max Load at Max Reach

1653.5 lb

Dimensions

Length to Fork Face

11.8 ft in

Width Over Tires

6.1 ft in

Overall Height

7 ft in

Wheelbase

6.6 ft in

Ground Clearance

1 ft in
