JCB 506C HL Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
20.08ft in
E
Ground Clearance
1.35ft in
B
Width Over Tires
8.08ft in
C
Overall Height
8.76ft in
D
Wheelbase
9.81ft in
Turning Radius Outside Tires
14.67ft in
Lift
F
Max Lift Height
42ft in
G
Max Forward Reach
22.74ft in
Max Load At Max Reach
1500lb
Max Load At Max Height
6000lb
Max Lift Capacity
6000lb
Specifications
Engine
Number Of Cylinders
4
Gross Power
82.5hp
Power Measured @
2200rpm
Max Torque
227lb ft
Torque Measured @
1400rpm
Displacement
268.6cu in
Aspiration
Naturally aspirated
Operational
Operating Weight
22020lb
Fuel Capacity
35gal
Hydraulic System Fluid Capacity
32gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Tire Size
13x24
Transmission
Transmission Type
JCB transmission incorporating torque converter; 4 speed syncroshuttle gearbox
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
15.5mph
Max Speed - Reverse
15.5mph
Hydraulic
Pump Type
Two stage gear pump with suction strainer and filter
Pump Flow Capacity
29.1gal/min
Relief Valve Pressure
3500psi
