JCB 412S Integrated Tool Carrier

JCB 412S Integrated Tool Carrier Specs front
JCB 412S Integrated Tool Carrier Specs front
JCB 412S Integrated Tool Carrier Specs extended_1
JCB 412S Integrated Tool Carrier Specs extended_1
JCB 412S Integrated Tool Carrier Specs extended_2
JCB 412S Integrated Tool Carrier Specs extended_2
JCB 412S Integrated Tool Carrier Specs extended_3
JCB 412S Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

20.15 ft in

B

Width Over Tires

7.46 ft in

C

Height to Top of Cab

9.61 ft in

D

Wheelbase

8.86 ft in

E

Ground Clearance

1.32 ft in

F

Hinge Pin Max Height

11.93 ft in

G

Dump Clearance at Max Lift

8.86 ft in

I

Fork Tine Length

4.01 ft in

K

Max Lift Height

11.32 ft in


Specifications

Engine

Engine Make

2257

Engine Model

444

Gross Power

121.4 hp

Net Power

110 hp

Power Measured @

2200 rpm

Max Torque

320.2 lb ft

Torque Measured @

1400 rpm

Displacement

271

Aspiration

turbocharged

Operational

Operating Weight

18038.3 lb

Fuel Capacity

33.1 gal

Cooling System Fluid Capacity

5.7 gal

Engine Oil Capacity

2.9 gal

Transmission Fluid Capacity

6.4 gal

Front Diff Fluid Capacity

6.7 gal

Rear Diff Fluid Capacity

6.7 gal

Hydraulic System Fluid Capacity

29.1 gal

Turning Radius

17.5 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

55 amps

Rear Axle Oscillation

25 degrees

Static Tipping Load - Bucket

8754.6 lb

Static Tipping Load - Forks

7372.3 lb

Tire Size

19.5LR24 XM27

Transmission

Transmission Type

smooth shift powershift

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed Forward

23.5 mph

Max Speed Reverse

16.6 mph

Hydraulic System

Pump Type

twin gear pumps

Relief Valve Setting

3190

Pump Flow Capacity

103.1 gal/min

Raise Time

4.6 sec

Dump Time

1.4 sec

Lower Time

3 sec

Bucket

Breakout Force

12971.5 lb

Bucket Capacity - heaped

1.4 yd3

Bucket Capacity - struck

1.1 yd3

Dimensions

Width Over Tires

7.5 ft in

Height to Top of Cab

9.7 ft in

Wheelbase

8.9 ft in

Ground Clearance

1.4 ft in

Hinge Pin Max Height

12 ft in

Length w/ Bucket on Ground

20.2 ft in

Dump Clearance at Max Lift

8.9 ft in

Reach at Max Height and Dump

3.5 ft in

Fork Tine Length

4.1 ft in

Max Lift Height

11.4 ft in
