JCB 300T Multi Terrain Loader

JCB 300T Multi Terrain Loader Specs front
JCB 300T Multi Terrain Loader Specs front
JCB 300T Multi Terrain Loader Specs back
JCB 300T Multi Terrain Loader Specs back
JCB 300T Multi Terrain Loader Specs extended
JCB 300T Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

B

Width Over Tracks

6.24 ft in

C

Height to Top of Cab

6.83 ft in

E

Ground Clearance

9.06 in

G

Clearance at Max Lift and Dump

7.85 ft in

H

Reach at Max Lift and Dump

2.96 ft in


Specifications

Engine

Emissions Certification

EPA-T4F (EU St3B)

Fuel

Diesel

Engine oil service interval hours

500

Starter motor

4.2 KW

Battery

12V

Engine Model

EcoMAX TCAE-55

Gross Power

73.8 hp

Cooling system

Liquid

Power Measured @

2400 rpm

Peak Torque

295.1 lb ft

Torque Measured @

1200 rpm

Displacement

268.5 cu in

Alternator

95 amps

Aspiration

Turbo

Operational

Operating Weight

11219.4 lb

Fuel Capacity

27.3 gal

Cooling System Fluid Capacity

4.1 gal

Engine Oil Capacity

4 gal

Hydraulic System Fluid Capacity

14.6 gal

Operating Voltage

12 V

Max Speed - low range

5.7 mph

Loader

Operating Load

11219.4 lb

Tipping Angle

8628 degrees

Bucket Capacity

0.6 yd3

Bucket Width

74.9 in

Undercarriage

Ground Pressure

4.8 psi

Width of Track

17.7 in

Hydraulic

Pump Flow

23 gal/min

Relief Valve Pressure

3335 psi

Dimensions

Angle of departure

29 degrees

Dig Depth

-393.7 in

Loadover height

9.5 ft in

Pin height

10.5 ft in

Rollback @ ground

30 degrees

Max. reach @ full height

4.3 ft in

Wheelbase

6.9 ft in

Reach @ ground level

3.7 ft in

Dump angle

42 degrees

Dump Height - Maximum

89.8 in

Width Over Tracks

6.3 ft in

Length with Bucket

12.5 ft in

Height to Top of Cab

6.9 ft in

Ground Clearance

9.1 in

Clearance at Max Lift and Dump

7.9 ft in

Reach at Max Lift and Dump

3 ft in
