JCB 210 Skid Steer Loader
Units
Dimensions
Dimensions
E
Ground Clearance
8.27in
D
Wheelbase
3.52ft in
Dig Depth
393.71in
Dump Angle
42degrees
Dump Height
7.42ft in
Loadover Height
9317.59ft in
Max. Reach @ Full Height
3.97ft in
Overall Height
6.5ft in
Overall Length
137.41in
Pin Height
9.85ft in
Quick Hitch Turning Radius
3.75ft in
Reach @ Ground Level
3.55ft in
Rear Chassis Turning Radius
5.42ft in
Rollback - Ground Level
30degrees
Angle Of Departure
25degrees
Width Over Tyres
59.85in
Bucket Corner Turning Radius
6.86ft in
Specifications
Tyres
Standard
10 x 16.5 - 8 PR Xtra Wall Off Road
Engine
Emissions Certification
EPA-T4F (EU St3B)
Fuel
Diesel
Starter Motor
2 KW
Battery
12 V
Hydraulically Driven Cooling Fan
Yes
Engine Oil Service Interval
500 hours
Engine Model
Kohler - KDI2504TCR/26A
Gross Power
73.8hp
Cooling System
Diesel
Power Measured @
2400rpm
Max Torque
221.3lb ft
Torque Measured @
1200rpm
Aspiration
Turbo
Displacement
2482cu in
Alternator
100amps
Capacities
Fuel Tank
24.4gal
Hydraulic System
11.5gal
Engine Oil
2gal
Engine Coolant
2.7gal
Operational
Sae Cab Operating Weight 1
6979.9lb
Sae Cab Operating Weight 2
7074.7lb
Roc With Full Counterweight
2237.7lb
Operational Weight
6885.1lb
Transmission
Model
Single Speed
Travel Speed
7.5mph
Loader
Tipping Load - Full Counterweight
4475.4lb
Loader Lift Capacity With Bucket
4131.5lb
Tipping Load - No Counterweight
4228.5lb
Breakout Force
3964lb
Bucket Capacity
0.5yd3
Bucket Width
66.2in
Hydraulic
Pump Flow Capacity
18.5gal/min
Relief Valve Pressure
483.8psi
