JCB 150T Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.52ft in
C
Height To Top Of Cab
6.57ft in
E
Ground Clearance
9.06in
G
Clearance At Max Lift And Dump
9.91ft in
H
Reach At Max Lift And Dump
3.25ft in
Wheelbase
1780 mm
Length With Bucket
11.46ft in
Angle Of Departure
27degrees
Dump Height
7.52ft in
Specifications
Engine
Emissions Certification
EPA-T4F (EU St3B)
Fuel
Diesel
Engine Oil Service Interval Hours
500
Starter Motor
2 KW
Battery
12 V
Engine Model
Kohler KDI 1903TCR/26B
Gross Power
56hp
Cooling System
Liquid
Power Measured @
2400rpm
Peak Torque
166lb ft
Torque Measured @
1200rpm
Displacement
113.5cu in
Alternator
100amps
Aspiration
Turbo
Operational
Operating Weight
8137.3lb
Cooling System Fluid Capacity
2.7gal
Engine Oil Capacity
2gal
Fuel Capacity
25.9gal
Hydraulic System Fluid Capacity
11.5gal
Transmission
Model
Single Speed
Travel Speed
6.3mph
Loader
Breakout Force
4012.5lb
Operating Load
8135.1lb
Tipping Angle
4283.6degrees
Bucket Capacity
0.5yd3
Bucket Width
66.2in
