Ingersoll Rand SD116F Vibratory Compactor
Units
Dimensions
Dimensions
A
Overall Length W/O Blade
19.35ft in
B
Width Over Tires
7.5ft in
C
Height To Top Of Cab
10.33ft in
D
Wheelbase
10.18in
Drum
F
Drum Diameter
50.99in
Centrifugal Force - High
60923.23lb
Pad Height
5in
Pad Surface Area
21in2
Vibration Frequency 1
34Hz
Vibratory Frequency 2
27.5Hz
Number Of Pads
112
Centrifugal Force - Low
59349.57lb
Drum Width
84.02in
Nominal Amplitude - High
0.09in
Nominal Amplitude - Low
0.06in
Specifications
Engine
Engine Make
2347
Engine Model
QSB5.9-3OT
Net Power
155hp
Aspiration
turbocharged
Operational
Operating Weight
25050lb
Fuel Capacity
68gal
Hydraulic System Fluid Capacity
22gal
Max Speed
7.8mph
Tires
23.1x26 8PR R1
Operating Voltage
12V
Alternator Supplied Amperage
95amps
