Ingersoll Rand SD105F Vibratory Compactor
Units
Dimensions
Dimensions
A
Overall Length W/O Blade
19.34ft in
B
Width Over Tires
7.5ft in
C
Height To Top Of Cab
10.33ft in
D
Wheelbase
10.18in
Drum
F
Drum Diameter
59.02in
Centrifugal Force - High
60698.42lb
Pad Height
4.02in
Pad Surface Area
21in2
Vibration Frequency 1
27.6Hz
Vibratory Frequency 2
33.8Hz
Number Of Pads
120
Centrifugal Force - Low
58899.95lb
Drum Width
84.02in
Nominal Amplitude - High
0.09in
Nominal Amplitude - Low
0.06in
Specifications
Engine
Engine Make
2347
Engine Model
B3.9 TAA Tier 2
Net Power
125hp
Aspiration
turbocharged
Operational
Operating Weight
25100lb
Fuel Capacity
68gal
Hydraulic System Fluid Capacity
22gal
Max Speed
6.5mph
Tires
23.1x26 8PR R1
Operating Voltage
12V
Alternator Supplied Amperage
95amps
