Ingersoll Rand PF6170 Asphalt Paver
Units
Dimensions
Dimensions
A
Length W/ Screed
17.17ft in
B
Transport Width
9.84ft in
C
Transport Height
11.67ft in
D
Wheelbase
8.59ft in
Tire Size
18x25
Width W/ Hopper Open
10.76ft in
Specifications
Engine
Engine Make
2347
Engine Model
QSB 6.7 Tier 3
Net Power
205hp
Power Measured @
1800rpm
Operational
Operating Weight W/O Screed
36122lb
Operating Weight W/ Screed
40652lb
Fuel Capacity
80gal
Hydraulic System Fluid Capacity
62.5gal
Hopper/Paver
Hopper Capacity
8.6lb
Paving Width - Std
10.1ft in
Paving Width - Max
26ft in
Paving Thickness - Max
12in
Paving Speed - Max
297ft/min
Travel Speed - Max
12mph
Auger Diameter
17in
