Hyundai R140LCM-7 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
25.46ft in
C
Shipping Height Of Unit
8.99ft in
I
Max Cutting Height
27.37ft in
J
Max Loading Height
19.36ft in
K
Max Reach Along Ground
24.74ft in
L
Max Vertical Wall Digging Depth
13.72ft in
M
Max Digging Depth
15.42ft in
Boom/Stick Option (Hex) 1
15'1 (4600mm) Boom / 6'3 (1900mm) Stick
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
25.63ft in
I
Max Cutting Height
27.6ft in
C
Shipping Height Of Unit
9.36ft in
J
Max Loading Height
19.62ft in
K
Max Reach Along Ground
25.33ft in
L
Max Vertical Wall Digging Depth
14.15ft in
M
Max Digging Depth
16.08ft in
Boom/Stick Option (Hex) 2
15'1 (4600mm) Boom / 6'11 (2100mm) Stick
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
25.5ft in
I
Max Cutting Height
28.68ft in
J
Max Loading Height
20.67ft in
C
Shipping Height Of Unit
9.22ft in
K
Max Reach Along Ground
26.68ft in
L
Max Vertical Wall Digging Depth
15.88ft in
M
Max Digging Depth
17.39ft in
Boom/Stick Option (Hex) 3
15'1 (4600mm) Boom / 8'2 (2500mm) Stick
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
25.63ft in
C
Shipping Height Of Unit
10.11ft in
I
Max Cutting Height
29.57ft in
J
Max Loading Height
21.53ft in
K
Max Reach Along Ground
28.22ft in
M
Max Digging Depth
19.03ft in
Boom/Stick Option (Hex) 4
15'1 (4600mm) Boom / 9'10 (3000mm) Stick
Max Vertical Wall Dig Depth
17.66ft in
Dimensions
E
Ground Clearance
1.97ft in
G
Height To Top Of Cab
10.11ft in
B
Width To Outside Of Tracks
9.32ft in
D
Length Of Track On Ground
9.95ft in
H
Tail Swing Radius
7.58ft in
Removal Counterweight Clearance
3.93ft in
Undercarriage
F
Track Gauge
6.7ft in
N
Shoe Size
31.5in
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.3mph
Ground Pressure
4.55psi
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
47
Drawbar Pull
29320lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2347
Engine Model
B3.9-C
Gross Power
115hp
Net Power
105hp
Power Measured @
2100rpm
Max Torque
330lb ft
Displacement
238cu in
Aspiration
Turbocharged
Torque Measured @
1500rpm
Operational
Operating Weight
37214.1lb
Fuel Capacity
71.4gal
Cooling System Fluid Capacity
6.4gal
Hydraulic System Fluid Capacity
55.5gal
Operating Voltage
24V
Engine Oil Capacity
4.1gal
Swing Drive Fluid Capacity
0.7gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4690psi
Hydraulic Pump Flow Capacity
68.7gal/min
Swing Mechanism
Swing Speed
13.6rpm
Buckets
Reference Bucket Capacity
0.8yd3
Minimum Bucket Capacity
0.4yd3
Maximum Bucket Capacity
1yd3
