Hyster S30FT DuraMatch Gas Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.81ft in
B
Overall Width
3.09ft in
C
Overall Height - Mast Lowered
6.83ft in
D
Wheelbase
4.3ft in
E
Ground Clearance
3.94in
G
Max Fork Height
10.56ft in
Right Angle Stack
7ft in
Turning Radius
5.83ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Lift Speed
114ft/min
Load Center
24in
Load Capacity
3000lb
Lower Speed
93ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
2357
Engine Model
FE
Power
46hp
Torque
104lb ft
Displacement
122.1cu in
Torque Measured @
1800rpm
Fuel Type
Gas
Operational
Operating Weight
6563.2lb
Tire Type
Cushion
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
10.9mph
