Hyster S3.5FT DuraMatch LPG Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
7.9ft in
B
Overall Width
3.52ft in
C
Overall Height - Mast Lowered
7.01ft in
D
Wheelbase
4.7ft in
E
Ground Clearance
3.51in
F
Height To Top Of Overhead Guard
6.99ft in
G
Max Fork Height
10.67ft in
Turning Radius
6.96ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Lower Speed
88.59ft/min
Load Capacity
7716.18lb
Load Center
19.69in
Lift Speed
98.43ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
2357
Engine Model
F2
Power
51hp
Power Measured @
2700rpm
Displacement
133.3cu in
Fuel Type
LPG
Operational
Operating Weight
10604.3lb
Tire Type
Solid
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
10.4mph
