Hyster H230HD2S Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
14.16ft in
B
Overall Width
8.09ft in
C
Overall Height - Mast Lowered
11.5ft in
D
Wheelbase
8.86ft in
E
Ground Clearance
9.85in
F
Height To Top Of Overhead Guard
9.92ft in
Front Tread Range
72.52in
Gradeability
44%
Rear Tread Range
75.99in
Turning Radius
12.89ft in
Mast
H
Mast Tip Forward
15degrees
I
Mast Tip Rear
12degrees
Load Center
24.02in
Load Capacity
23000.83lb
Lift Speed
79ft/min
Lower Speed
98ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
Cummins
Engine Model
QSB 4.5
Power
159.6hp
Torque
460.3lb ft
Power Measured @
2300rpm
Displacement
272cu in
Torque Measured @
1500rpm
Fuel Type
Diesel
Operational
Operating Weight
31510.7lb
Tire Type
Pneumatic
Number Of Front Wheels
4
Number Of Rear Wheels
2
Drawbar Pull
21400lb
Oil System Fluid Capacity
26.5gal
Operating Voltage
24V
Fuel Capacity
27.5gal
Front Tire Size
10.00-20 16PR
Hydraulic System Fluid Capacity
35.7gal
Rear Tire Size
10.00-20 16PR
Alternator Supplied Amperage
120amps
Axle Load - Front
49941lb
Axle Load - Rear
4570lb
Transmission
Number Of Forward / Reverse Speeds
3 / 3
Drive System
Powershift Transmission
Transmission Type
ZF WG161
Brakes
Service Brake
Oil immersed (wet) disc
Parking Brake
Spring applied, dry disc on drive axle
