Hyster E35HSD (18\"Battery Comp) Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
5.61ft in
B
Overall Width
3.51ft in
C
Overall Height - Mast Lowered
6.83ft in
D
Wheelbase
3.66ft in
E
Ground Clearance
3.94in
F
Height To Top Of Overhead Guard
7.32ft in
G
Max Fork Height
10.61ft in
Right Angle Stack
9.69ft in
Turning Radius
4.59ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Number Of Mast Sections
2
Lower Speed
90ft/min
Load Center
24in
Load Capacity
3500.95lb
Lift Speed
95ft/min
Specifications
Engine
Fuel Type
Electric
Operational
Operating Weight
8972.9lb
Tire Type
front rubber, rear poly 92D
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
7.1mph
