Hyster E30HSD3 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
5.2ft in
B
Overall Width
3.51ft in
C
Overall Height - Mast Lowered
6.99ft in
D
Wheelbase
3.29ft in
E
Ground Clearance
4.02in
F
Height To Top Of Overhead Guard
7.33ft in
Front Tread Range
35in
Gradeability
15%
Rear Tread Range
24.49in
Right Angle Stack
5.67ft in
Turning Radius
4.23ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Load Capacity
3000.5lb
Max Fork Spread
131.19in
Lower Speed
63ft/min
Lift Speed
87ft/min
Load Center
23.98in
Specifications
Engine
Engine Make
Hyster
Engine Model
E30HSD3
Operational
Operating Weight
6353.8lb
Tire Type
Rubber
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
7.3mph
Drawbar Pull
2602lb
Front Tire Size
18 x 7 - 12.1
Rear Tire Size
10 x 5 - 6.5
Axle Load - Front
3991lb
Axle Load - Rear
4462lb
