Hitachi ZX70LC Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
19.95ft in
C
Shipping Height Of Unit
8.54ft in
I
Max Cutting Height
23.46ft in
J
Max Loading Height
16.61ft in
K
Max Reach Along Ground
20.25ft in
L
Max Vertical Wall Digging Depth
12.24ft in
M
Max Digging Depth
13.69ft in
Boom/Stick Option (Hex) 1
Boom 12ft 2in (3720mm)/Stick 5ft 4in(1620mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
20.08ft in
C
Shipping Height Of Unit
9.45ft in
I
Max Cutting Height
24.78ft in
J
Max Loading Height
17.89ft in
K
Max Reach Along Ground
21.89ft in
M
Max Digging Depth
15.33ft in
L
Max Vertical Wall Digging Depth
14.05ft in
Boom/Stick Option (Hex) 2
Boom 12ft 2in (3720mm)/Stick 6ft 11in (2120mm)
Dimensions
B
Width To Outside Of Tracks
7.62ft in
D
Length Of Track On Ground
7.52ft in
E
Ground Clearance
1.19ft in
G
Height To Top Of Cab
8.54ft in
H
Tail Swing Radius
5.75ft in
Removal Counterweight Clearance
2.5ft in
Undercarriage
N
Shoe Size
17.72in
F
Track Gauge
6.14ft in
Ground Pressure
4.36psi
Number Of Shoes Per Side
40
Max Travel Speed
3.1mph
Number Of Track Rollers Per Side
5
Number Of Carrier Rollers Per Side
1
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
CC-4JG1
Net Power
52hp
Power Measured @
2100rpm
Displacement
186.7cu in
Max Torque
141.7lb ft
Torque Measured @
1800rpm
Operational
Operating Weight
16248.1lb
Fuel Capacity
35.7gal
Cooling System Fluid Capacity
2.6gal
Hydraulic System Fluid Capacity
26.5gal
Operating Voltage
24V
Engine Oil Capacity
3.2gal
Hydraulic System Relief Valve Pressure
4554.2psi
Hydraulic Pump Flow Capacity
47.2gal/min
Swing Mechanism
Swing Speed
11.3rpm
